Description
| Technical Specifications | |
| Motor Power | 5.5KW |
| Oil Capacity | 80lt |
| Weight | 1475kg |
| Dimensions (LxWxH) | 1480x1450x1780mm |
| Punching | |
| Punching pressure | 60ton |
| Punch Capacity (Max diameter x thickness) | 40 x 10mm |
| Punch Capacity (Diameter x max thickness) | 20 x 20mm |
| Throat Depth | 250mm |
| Stroke Length | 60mm |
| Cycles/Min (15mm stroke) | 38 pieces |
| Table Size | 550 x 370mm |
| Flat Shearing | |
| Flat Bar (Max thickness) | 200 x 20mm |
| Flat Bar (Max width) | 300 x 15mm |
| Blade Length | 310mm |
| Angle Flange Trim | 60mm |
| Angle Shearing | |
| At 90 Shearing | 120 x 120 x 10mm |
| At 45 Mitre shearing | 70 x 70 x 7mm |
| Bar Shearing | |
| Round Bar Shearing | 16-40mm |
| Square Bar Shearing | 16-40mm |
| Working Height | 1100mm |
| Notching | |
| Material Thickness | 10mm |
| Rectangular Notcher (width) | 42mm |
| Rectangular Notcher (depth) | 90mm |
| Vee Notcher (Side x Side x T) | 42 x 42 x 10mm |
